Features

• Working pressure:
  • 16 Bar (Size – DN50 to DN600)
  • 25 Bar (Size – DN50 to DN300)
• Connection ends: Available with flange conforming to ASME B16.1 Class 125, ANSI B16.2 Class 250 (Other types available on request)
• NPT or BSPT blowoff outlet on body. Blowoff outlets are finished with plugs
• Screens are perforated 304 Stainless steel with spot welded seam.
• Temperature range: -10ºC to 120ºC
• Coating: internally and externally liquid epoxy painted or fusion bonded epoxy powder coated (FBE)
