Features and Functions

Professional and Reliable

• New logical and visualized GUI design
• Dual-OS design to ensure high reliability of system running
• ANR technology to enhance the storage reliability when the network is disconnected
• HDD hot swap with RAID0, RAID1, RAID5, RAID6, and RAID10 storage scheme configurable
• Configurable normal or hot spare working mode to constitute an N+1 hot spare system

Video Input and Transmission

• Up to 64-ch 12 MP IP cameras can be connected
• Connectable to the third-party network cameras

Compression and Recording

• H.265+ compression effectively reduces the storage space by up to 75%
• Full channel recording at up to 12MP resolution

HD Video Output

• HDMI1/VGA1 and HDMI2/VGA2 outputs provided
• HDMI1 Video output at up to 4K (3840 × 2160) resolution

Storage and Playback

• Up to 8 SATA interfaces and 1 eSATA interface for HDD connection
• 10TB capacity for each HDD
• Smart search for efficient playback
• 16-ch synchronous playback at up to 1080p resolution
• Normal/Important/Custom video playback
• Important files management
• HDD health monitoring

Smart &POS Function

• Supports multiple VCA (Video Content Analytics) events
• Smart search for the selected area in the video; and smart playback to improve the playback efficiency
• Supports VCA search for fire/ship/temperature/temperature difference detection triggered video files
• POS information overlay on live view and playback
• POS triggered recording and alarm

Network & Ethernet Access

• Hik-Connect for easy network management
• 2 Gigabit Ethernet network interface
