Specifications
| Materials | Ductile iron ASTM A536, BS EN 1563 Malleable Iron BS EN 1562 | |
|---|---|---|
| Max. Working Pressure | 500 PSI | |
| Dimensions | American Standard ASME B16.3, B16.4, B16.14, Unions B16.39 British Standard BS EN 10242, BS 143 & 1256 |
|
| Threads | American Standard ANSI B1.20.1 British Standard BS 21, ISO 7/1 (Taper) |
|
| Finish | Black or hot dipped galvanized | |
