    Open Area Sounder

    SHIELD Open-Area Sounder has been designed for use in open areas and can be connected to any UL or SHIELD system.

    Click here to download the catalogue

    SHIELD Open-Area Sounder has been designed for use in open areas and can be connected to any UL or SHIELD system.

    Click here to download the catalogue

    Features

    • Self-test trouble monitoring
    • Two volume settings 92dB(A) and 100dB(A)
    • Synchronization of tones
    • Individual and group addressing
    • Available in red or white
    • Loop-powered
    • IP65 rated

    Specification

    Operating Voltage 17 – 28 V DC
    Maximum Low Current at 24 V Normal Standby < 310μA
    Operated 28V Highest Audibility 5.4 mA
    Operated Switch On Surge < 6 mA for IS
    IP Rating 65
